Quick Details

  • Type: Coding Machine
  • Condition: New
  • Automatic Grade: automatic
  • Application: PACKAGE MACHINE, LABELING MACHINE, ETC., Horizontal/Vertical Package Machine, Labeling Machine, etc.
  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: DK
  • Model Number: D03 Coding Machine for Pouches
  • Packaging Material: Paper
  • Packaging Type: Cartons
  • Driven Type: Electric
  • Voltage: AC 110-220V
  • Power: 200W
  • Dimension(L*W*H): 188*190*180
  • Weight: 10KG
  • Certification: CE SGS
  • After-sales Service Provided: Overseas third-party support available
  • Surface Speed: 40meters per minute
  • Print Speed: Continuous: max. 40 meters/minute; Intermittent: 450ppm
  • Print Contents: Bar Code, QR Code, Image, Variable Information, etc.
  • Print Area: Continuous: 32*100mm; Intermittent: 32*60mm
  • Print Head: 32mm width, 300 dpi (12 dots/mm)
  • Printer Size: 188*190*180mm
  • Control Box Size: 210*180*155mm
  • Company History: 20 years experience in coding area
  • Market Share: 4000 customers, 80% of Chinese market

Packaging & Delivery

Packaging Details in standard export carton package
Delivery Time 1-2 weeks after order confirmation



Product Description



D03 Coding Machine for Pouches is DIKAI own researched TTO machine. DIKAI R&D team spent 4 years to finish this project and tested it in domestic market for over 4 years, improvements and such efforts have been adopted accordingly according to our 4000+ end users and . Till now, we have sold 3000 units inside & outside China with satisfactory feedback.



Now we have 3 different sizes print heads for your choice and also self-made ink roll coders, hot stamping coders, case & carton coders and all their consuambles, please feel free to contact us for details at any time.



DIKAI attends over 10 exhibitions all around the world each year, information will be updated in our front page for your view.



D03 Coding Machine for Pouches Specifications:



Print Head32mm, 300DPI
Print AreaIntermittent-32mm*60mm
 Continuous-32mm*100mm
Ribbon SizeW-33MM, L-600(Max.)
Print FrequencyIntermittent:up to 350PPM
 Continuous:up to 200PPM
PowerAC110~220V, 50/60Hz, 150W
Environmental Operating Temperature 0~40°C
Relative Humidity 10%~95% ( no condensing)
Air Supply  6bar/90PSI(MAX) dry uncontaminated
Weight  Intermittent-print head:8.5kg, control box:2.0kg
Dimension Print Head 188mm*190mm*180mm(L*W*H)
  Control Box 175mm*210mm*110mm(L*W*H)





 D03 Coding Machine for Pouches Key Features:
•Patented long life mechanical design
• Max 53mm x 70mm print area for intermittent and 53x100mm for continuous mode
• 500m ribbon capacity
• Print Quality 300dpi (12 dot / inch).
• Up to 600mm per second print speeds
• The USB can be used to:  Move messages and configurations between printers for local based set-up
Back-up and restore messages and printer settings
• Large memory for all label formats to be stored locally.





Packaging & Shipping



Package: In standard export carton package:

Print head & control box in a carton; Mounting bracket & other spare parts in another carton to well protect the machine.

Lead time: 1-2 weeks after order confirmation.
